Synthes 202.824 2.7mm Cortex Screw Self-Tapping 24mm Orthopedic Hardware

Synthes 202.824 2.7mm Cortex Screw Self-Tapping 24mm Orthopedic Hardware

As a 2.7mm diameter screw with a 24mm length, it is a foundational component of the Synthes Small Fragment and Mini-Fragment LCP (Locking Compression Plate) sets. This screw is engineered to provide stable, bicortical fixation in mid-sized bones of the hand, foot, and distal radius.

Technical specifications

• Brand: Synthes
• Reference / model: 202.824
• Model: / REF: 202.824
• Material: 316L Stainless Steel (Surgical Grade)
• Dimensions / sizes: 2.7mm, 24mm

Additional product details

• Manufacturer: Synthes (DePuy Synthes)
• Screw Diameter: 2.7 mm
• Thread Profile: Self-Tapping / Fully Threaded
• Screw Length: 24 mm
• Thread Pitch: 1.0 mm
• Core Diameter: 1.9 mm
• Head Type: 5.0 mm Head with Small Hexagonal Socket
• Quantity: Individually Packaged, Sterile
• Bicortical Stability: At 24mm, this screw is frequently utilized for bicortical fixation in the metacarpals, metatarsals, or fibula, where the screw engages both cortical walls for maximum pull-out resistance.
• 316L Stainless Steel Biocompatibility: Cold-worked for high fatigue strength, the material is biologically inert and designed to maintain its mechanical properties throughout the biological stages of bone healing.
• Hand & Wrist Surgery: Fixation of metacarpal shaft fractures or corrective osteotomies.
• Foot & Ankle Surgery: Stabilization of metatarsal fractures and midfoot fusions.
• Trauma Surgery: Fixation of cortical fragments in the distal radius or fibula.
• Mini-Fragment Plating: Used as a neutralization or compression screw within 2.7mm plating constructs.
• Status: NEW — Factory Sealed & Sterile.
• Integrity: This implant is securely packaged within its original manufacturer's sterile peel-pouch. The packaging is intact, ensuring the product's sterility, material integrity, and full lot traceability for clinical implantation in 2026.

Condition

New.
