Enmind EN-S9 Smart Syringe Pump - 4.3" Touchscreen Micro-Infusion System

Enmind EN-S9 | Smart Syringe Pump | 7-Inch High-Def Touchscreen

The Enmind EN-S9 is a flagship micro-infusion system designed for 2026 clinical standards in neonatal care and anesthesia. Moving beyond the standard 4.3-inch displays of previous generations, the EN-S9 features an oversized 7-inch true-color capacitive touchscreen, providing the largest and most intuitive interface in its class.

Engineered with a fully automatic slider box, the EN-S9 eliminates the risks associated with manual syringe loading. It offers peerless micro-infusion precision (0.01 ml/h increments) and a comprehensive drug library, making it the premier choice for delivering high-potency, life-sustaining medications.

Key Advantages: The Smart Syringe Standard

• Fully Automatic Loading: The motorized slider box precisely detects and loads the syringe automatically, ensuring a perfectly smooth infusion start and reducing the risk of mechanical errors.

• Large 7-Inch Display: The smartphone-style tablet interface allows clinicians to view all critical parameters—including real-time pressure graphs and titration curves—at a glance.

• Universal Syringe Recognition: Automatically identifies syringe sizes from 1ml, 2ml, 5ml, 10ml, 20ml, 30ml, and 50/60ml across all major brands.

• DERS Safety System: Supports Dose Error Reduction Software (DERS) with a library of up to 5,000 color-coded drugs, allowing for strict hard and soft dosage limits.

Technical Specifications & Precision

• Infusion Accuracy: +/- 1.8% (Clinical-grade precision for high-alert drugs).

• Flow Rate Range: 0.01 ml/h to 2300 ml/h (Minimum increment of 0.01 ml/h).

• Bolus Rate: 0.01 ml/h to 2300 ml/h (Programmable Automatic and Manual modes).

• KVO (Keep Vein Open) Rate: 0.01 to 10 ml/h (Adjustable).

• Occlusion Levels: 15 selectable levels (ranging from 50mmHg to 1125mmHg).

• Battery Performance: Lithium polymer battery providing up to 12 hours of operation; recharges in under 5 hours.

Safety & Advanced Features

• Dual-CPU Architecture: Real-time cross-monitoring between two independent processors ensures the pump stops instantly if any system discrepancy is detected.

• Dynamic Pressure System (DPS): Provides both numerical and graphical pressure monitoring to detect downstream occlusions before they impact the patient.

• Relay Infusion: Supports IrDA-based relay between multiple pumps, allowing for continuous, uninterrupted medication cycles without manual intervention.

• Anti-Bolus Technology: Automatically vents the line pressure after an occlusion to prevent a sudden accidental dose delivery upon clearing the blockage.

• IP44 Waterproof Rating: Certified for protection against splashes from any direction, essential for active OR and ICU environments.

Specialized Infusion Modes

The EN-S9 is equipped with 11+ clinical modes to support complex pharmacological protocols:

1. TIVA Mode: Optimized for Total Intravenous Anesthesia.

2. Body-Weight/Dose Mode: Auto-calculates based on mcg/kg/min or mg/kg/h.

3. Loading-Dose Mode: Initial bolus followed by a maintenance rate.

4. Sequence/Cascade Mode: Multi-step or multi-pump relay programs.

5. Ramp Up/Down: Gradual dosage adjustments for sensitive medications.

6. Micro Mode: Limits maximum flow rates to ensure safety for neonatal patients.

Condition & Quality Assurance

• Status: NEW — 2026 flagship model.

• Connectivity: WiFi-enabled for Central Monitoring System (CMS) integration and automated history logs (5,000+ entries).

• Design: Lightweight and stackable with a rotatable pole clamp for vertical or horizontal mounting.
